Model型号 | CF-HM100 |
Feeding Size进料口尺寸 | 650mmx400mm |
Screw diameter螺杆直径 | φ138mm |
Screw Length螺杆长度 | 1090mm |
Screw Speed螺杆速度 | 165rpm |
Extrusion center hight挤出中心高度 | 250mm |
Heating power加热功率 | 3kw |
Main motor power主电机功率 | 7.5kw |
Screen Size滤网孔径 | 40mm |
Blade rotation diameter刀片回转直径 | 250mm |
Blades quatity刀片数量 | 12sets |
Blades rotation speed刀片回转直径 | 150rpm |
Size机器尺寸 | 1200x1000x1400 |
Weight重量 | 800kg |
Capacity产量 | 50kg/h |
